1-Inch PVC Nylon 90° Elbow Fitting - MPT x Barb Connector for Vianti Falls Spillway

1-Inch PVC Nylon 90° Elbow Fitting - MPT x Barb – This EasyPro 90-degree elbow redirects water flow around corners in Vianti Falls spillway installations. The MPT x barb configuration threads into the spillway on one end and accepts flexible PVC tubing on the barb end, making it ideal for tight-space routing.

Specifications

• Size: 1-inch fitting
• Configuration: Male Pipe Thread x Barb
• Material: Schedule 40 PVC with nylon reinforcement
• Angle: 90 degrees
• SKU: TA100E

When to Use This Fitting

Choose the 90° elbow when you need a sharp directional change — for example, routing pipe straight down from a wall-mounted spillway or turning a corner around a structural post. The barb end grips flexible PVC tubing with a hose clamp for a secure, vibration-resistant connection that won't loosen over time.

Installation

Wrap the MPT threads with Teflon tape (3-4 wraps clockwise) before threading into the spillway fitting. On the barb end, slide the hose clamp onto the tubing first, push the tubing over the barb until fully seated, then tighten the clamp. Sold separately from Vianti Falls kits.
