This unit can aerate up to 6 acres if you have the correct depths. At 9.5 CFM this is a powerful compressor that will get the job done. It is a rotary vane compressor and is sure to have a long life. When you need pond aeration for 2 big ponds this is the least expensive and yet most effective way to go. You can't beat diffused aeration when it comes to bringing life and oxygen to your pond. We recommend the rotary vane compressors over piston type compressor on all ponds that are less than 18' deep.

Kit Includes:

• 3/4 HP Gast Rotary Vane Compressor
• Lockable Steel Compressor Cabinet
• Includes 600' 1/2'' Weighted Tubing
• Four dual head air diffusers
• 4 valve outlet assembly
• Fittings and clamps
• Can be use as a deicer in the wintertime

All systems come with compressor installed in cabinet with valved outlets, pressure gauge, pressure relief and air filter installed as well.

•    Cabinets include cooling fan and electrical outlet pre- installed
•    Warranties: Compressors - 1 year, cabinets - 5 years, diffusers - 5 years

Max Depth	Max Pond Size
5-8 feet	1 ½  acres
8-12 feet	3 acres
12-18 feet	6 acres

* Please note when selecting your aerator that the greater the depth of your pond, the less CFM(Cubic Feet per Minute) of air required to adequately aerate the pond.


PDF Files:

Pond Aeration System Instruction Booklet
