The 8400JF (1 Phase) plus 2.3JF (Three Phase) 2 horse power floating
ornamental fountain fantastic for bigger ponds or when several big
patterns are preferred.
It can be obtained in a standard 5 interchangeable nozzles; asideit can
function without a nozzle giving you six fountain patterns for just the
cost of one.
The dimensions of the six fountain patterns range from twenty two
inches in height to more than forty inches in diameter. With six
multiple fountain designs, you are free to modify the aerating fountain
so as to match your tastes, weather conditions as well as your pond.
The 2.3JF and 8400JF are specially designed to maximize the flow of
oxygen and provide utmost benefit to your lake or pond.
It can be obtained in a 38V and 240V, 50 Hertz international Model or a
208/240Vac three phase and 240 volts Single Phase, 60 Hertz model.
The 8400JF, one phase unit comes with a cutting edge control panel
protected by GFCB, model C-85. Surge protection, hardwire terminal
block, timer for the functional light unit, and fountain timer are all
included in the control panel. These are contained within a
thermoplastic NEMA 3r /4x rated enclosure. Kasco advises that you get a
qualified electrician to mount the fountain hook up and C-85 control.
The 2.3JF, three phase unit comes with a user friendly,
all-encompassing three phase control panel that is GFI protected, model
CF-3235. These panels have the finest features, aside from the
confusing options. This non metallic, UL-508A, 4x /3r panel comes with
a true, three phase rated GFCI protection for personnel with a 5 micro
ampere trip level. It also has motor starter plus adjustable overload,
surge/lightening protection, a Hand-Off Automatic switch, and two round
the clock time clocks. Other elements include input stations for field
installed inter lock, startup directions with wiring diagram within the
door, and a wiring terminal block to make installation easy. The
control panel should be installed by a qualified electrician.
To extend its loveliness into the nighttime periods, you can include a
non-compulsory
LR-375
Light Kit Low Voltage. Lighting
livens up the
water spectacle, turning drops of water into glistening light jewels
even as it creates an entrancing atmosphere to your water body at
nighttime.
The LR-375 Light Kit Low Voltage has 3 machined-bronze light fittings
each with 75W MR16 Halogen lamps. There is no need for extra wiring
because the transformer of the lighting unit is incorporated into the
system. You only need to plug the unit into the C85 Control Panel. You
can also wire into the CF32353 Phase panel. The lights will work any
time the unit works during hours of darkness or when the timer of the
lighting system is set (for three phase options). Each kit comes with 3
clear MR16 lamps. You have the option of choosing any or all the
discretionary colors of Yellow, Blue, Green and Red. To create more
spectacular displays, you can add 2 collections of LR375 lights.
The Kasco 8400JF Includes These 6
Nozzles:
Benefits and Features of the
2.3JF and 8400JF:
- Multiple Patterns within a
Unit: the unit can be custom-configured to meet your personal tastes as
well as your precise project requirements.
- Clog Resistant: It is
extremely clog resistant due to its exceptional water-deflecting nozzle
pattern. Successful shallow water works in 20".
- Rugged Motor: Eco-friendly
design and a Hard-face interior mechanical seal plus exterior lip seal
to prevent leaks. Long-life bottom and top ball bearings. Silicone
carbide are used as seals for long life. Flood oil lubricated to
provide good dissipation of heat.
- Corrosion Resistant: Highly
reliable in corrosive environments such as salt-water. All exterior
metal motor, hardware components, float are all made of stainless steel
and protected by an oblation zinc anode.
- Low Maintenance: The motor
housing should be cleaned one or two times each year and the zinc anode
should be replaced when it is noticeably corroded.
- Tested Completely: ETL
listed to strict CSA and UL safety norms.
- Ships Easily: By means of
UPS within three or four boxes (Include a box for lights)
- Reliable: Offered with a
3-year warranty
- Cord Length choices: SOOW or
SJTOW under water rated, cord length choices of four hundred inches,
three hundred inches, two hundred and fifty inches, two hundred inches,
one hundred and fifty inches, fifty inches, (five hundred inches
special order). Comes with three 50 inches braided nylon moorage ropes.
- Manufactured in the United
States of America.
